Existing Conditions Battery Place to 59th Street
← WEST / River
EAST / Buildings →
Total: 116 ft
Your Proposed Design Battery Place to 59th Street
← WEST / River
EAST / Buildings →
Drag blocks from the palette below to design your cross section
0 / 116 ft
Block Palette — Drag onto Road Canvas
📋 Submit Your Design
Share your proposed cross section with the project team. Your input helps shape the future of Route 9A.
1 Submitting design for: Southern / Battery Park
✅ Thank you! Your design has been submitted successfully.
* Required fields. Submissions are stored securely for project team review.
📊 Community Results
Aggregated data from all submitted designs. Updated in real time.
About This Tool

This interactive cross section builder replicates the physical block exercise conducted at Public Meeting 2 of the Route 9A / West Side Highway study. It allows community members who could not attend to participate online and submit their ideal roadway cross section design within the allowable Right-Of-Way for your section.

"In case you missed Public Meeting 2, we conducted an extensive block exercise where community members designed their ideal cross section for Route 9A. Now it's your turn. Here is your opportunity to provide your input and tell us how you'd like to see the West Side Highway redesigned."

HOW TO USE
  1. Review the Existing Conditions in the top panel
  2. Drag blocks from the palette onto the bottom canvas
  3. Click a block to resize or add a label
  4. Drag blocks left/right to reorder
  5. Watch the ROW gauge — stay within the total width
  6. Fill out the submission form and submit
BLOCK TYPES
PROJECT INFO

Study: Route 9A / West Side Highway
Corridor: Battery Place to 59th Street
Agency: NYSDOT
Website: westsidehighwaystudy.com
Tool Version: 1.0 — March 2026
